Principle:

Intelligent liquid level sensor is a set of liquid level measurement, display, output, control in one of the intelligent digital display measurement and control products. The product is fully electronic structure, the front end of the isolation membrane filled oil piezoresistive sensor, by high precision A/D conversion, microprocessor operation processing, field display, and output one analog and two switch. The intelligent digital sensor is flexible in use, simple in operation, safe and reliable.

Technical parameters

◇ Measuring range: 0~500mm~2500mm

Overload capacity: 200%

◇ Stability: ≤0.1%/ year

◇ Display mode: 4 digit digital tube

Response time: < 30ms

◇ Relative humidity: ≤80%

◇ Accuracy level: 0.5%F.S

Power supply: 24VDC/220VAC(optional)

◇ Switch output: 4 relay

Switching load: 24VDC/10A,220VAC/2A

◇ Current type analog output: ≤±0.5% range

Output type: 4... Can be set to 20 ma

Load RA: 0.5 KOhm or less

Linearity: ≤0.5% range

◇ Communication mode: RS485 custom

Wiring protection: reverse phase, overload, paragraph protection

His display:

Design: Red 4-bit 8mm high brightness LED

Display range: 999... 9999

Accuracy: ≤±0.5% range

◇ Stability (annual drift) : ≤±0.3% range

His temperature:

Medium temperature: -20... 85 ° c.

Ambient temperature: -20... 80 ° c.

Storage temperature: -30... 80 ° c.

Cardiac materials:

Case: aluminum oxide

Medium contact part: stainless steel

Protection class: IP67
